Name: Streams

Display Field: Name

Type: Feature Layer

Geometry Type: esriGeometryPolyline

Description: This line feature class represents the natural and modified open surface watercourses, creeks, and tributaries flowing across the City of Grapevine jurisdiction and its surrounding watersheds.Data Provenance & Compilation History:Historical Foundation: Stream geometries were primarily derived from local tributary alignments delineated within the City of Grapevine Master Drainage Plan (April 1993).Multi-Source Compilation: Supplemental stream reaches and channel alignments were gathered and integrated from various state, federal, and local hydrographic sources (including USGS NHD data and high-resolution aerial imagery).Database Integration: Formally staged and loaded into the enterprise geodatabase on August 9, 2022 (2022-08-09).Maintenance & Update Frequency: As Needed / Historical Baseline (Loaded into the SDE geodatabase on August 9, 2022; updated periodically as stream restoration projects, channel modifications, or re-delineations occur).Process Step (Lineage Description):Master Plan Extraction: Primary stream centerlines digitized from printed maps and hydrologic figures in the City of Grapevine Master Drainage Plan (April 1993).Multi-Source Synthesis: Stream channels reconciled against supplemental USGS National Hydrography Dataset (NHD) flowlines and local aerial orthophotography.Enterprise Migration: Staged and loaded into the enterprise SDE geodatabase structure on 2022-08-09.

Service Item Id: 6ff0f954a2554bbf8d4b995c9be34043

Copyright Text: Historical engineering study: City of Grapevine Master Drainage Plan (April 1993). Data compilation, spatial reconciliation, and enterprise maintenance by City of Grapevine Public Works GIS.

Default Visibility: true

Max Result Window: N/A

Max Record Count: 2000

Standard Max Record Count No Geometry: 32000

Max Record Count Factor: 1

Standard MaxRecord Count: 8000

Tile Max Record Count: 4000

MaxSelectionCount: 2000

Supported Query Formats: JSON, geoJSON, PBF

Min Scale: 0.0

Max Scale: 0.0

Supports Advanced Queries: true

Supports Statistics: true

Has Labels: true

Can Modify Layer: true

Can Scale Symbols: false

Use Standardized Queries: true

Supports Datum Transformation: true

Extent:

XMin: 2387013.6098727137
YMin: 7003724.000100732
XMax: 2426444.469002977
YMax: 7048189.500080317
Spatial Reference: 102738  (2276)

Drawing Info:

Renderer:
Simple Renderer:
Symbol:
Style: esriSLSSolid
Color: [0, 197, 255, 255]
Width: 2
Label: N/A
Description: N/A
Transparency: 0
Labeling Info:
Label Placement: esriServerLinePlacementAboveAlong
Label Expression: [Name]
Use Coded Values: true
Symbol:
Color: [0, 112, 255, 255]
Background Color: N/A
Outline Color: N/A
Vertical Alignment: bottom
Horizontal Alignment: center
Right to Left: false
Angle: 0
XOffset: 0
YOffset: 0
Size: 10
Font Family: Times New Roman
Font Style: italic
Font Weight: bold
Font Decoration: none

Min. Scale: 0.0
Max. Scale: 0.0

Feature Draw Order:

N/A

Advanced Query Capabilities:

Supports Statistics: true
Supports OrderBy: true
Supports Distinct: true
Supports Pagination: true
Supports Result Pagination Token: false
Supports TrueCurve: true
Supports Returning Query Extent: true
Supports Query With Distance: true
Supports Sql Expression: true
Supports Query With ResultType: true
Supports Returning Geometry Centroid: false
Supports Binning LOD: false
Supports Query With LOD Spatial Reference: false
Supports Percentile Statistics: true
Supports Having Clause: true
Supports Count Distinct: true
Supports Time Relation: true
Supports Sql Format: false
Supports Query Analytic: true
Supports Query With Cache Hint: false
Supports Query With Current User: true
Supports Query With Result Type: true

HasZ: false

HasM: false

Has Attachments: false

Has Last Edit Time: false

HTML Popup Type: esriServerHTMLPopupTypeAsHTMLText

Type ID Field: N/A

Fields:

• OBJECTID ( nullable: false, alias: OBJECTID, type: esriFieldTypeOID )
• StreamNumber ( nullable: true, alias: Stream #, type: esriFieldTypeInteger )
• StreamID ( nullable: true, alias: Stream Identifier, type: esriFieldTypeInteger )
• Name ( nullable: true, length: 50, alias: Name, type: esriFieldTypeString )
• Miles ( nullable: true, alias: Miles, type: esriFieldTypeDouble )
• Shape ( nullable: true, alias: Shape, type: esriFieldTypeGeometry )
• LastUpdate ( nullable: true, length: 8, alias: Last Edit Date, type: esriFieldTypeDate )
• Length ( nullable: true, alias: Length (ft), type: esriFieldTypeDouble )
• Shape.STLength() ( nullable: true, alias: Shape.STLength(), type: esriFieldTypeDouble )

Supported Operations:   Query   Query Attachments   Query Analytic   Generate Renderer   Return Updates

  Iteminfo   Thumbnail   Metadata
