Name: Sidewalk Data IMS

Display Field: Segment_ID

Type: Feature Layer

Geometry Type: esriGeometryPolyline

Description: This line feature class stores sidewalk inventory and condition assessment data captured alongside the September 2018 citywide pavement inspection survey conducted by Infrastructure Management Services (IMS) for Grapevine, Texas.Inspection Scope & Enterprise Integration:Data Collection Methodology: Concurrently evaluated during the mobile mapping pavement survey, recording presence, placement, material type, structural condition, and visible distresses for pedestrian sidewalks along city-maintained roadways.Database Relational Integrity & Asset Linking:Segment_ID / pvmt CARTE_ID: Uniquely matches the corresponding pavement asset ID (CARTE_ID) within the Public Works enterprise database (GVPWorks.dbo.Pavement).Enables direct relational queries, join views, and asset cross-referencing between roadway pavement segments and adjacent pedestrian sidewalks.Municipal Application: Serves as a primary baseline dataset for evaluating sidewalk coverage, identifying damaged or failing sidewalk panels, prioritizing ADA accessibility upgrades, and planning sidewalk maintenance budgets.

Service Item Id: 01688493526d4689bd555a10a36af2d7

Copyright Text: Vendor Field Survey & Data Capture: Infrastructure Management Services (IMS) (1820 W Drake Dr., Tempe, Arizona 85283; Ph: 480-839-4347; Completed 09/12/2018). Database integration and Cartegraph linkage by City of Grapevine Public Works Department GIS.

Default Visibility: true

Max Result Window: N/A

Max Record Count: 2000

Standard Max Record Count No Geometry: 32000

Max Record Count Factor: 1

Standard MaxRecord Count: 8000

Tile Max Record Count: 4000

MaxSelectionCount: 2000

Supported Query Formats: JSON, geoJSON, PBF

Min Scale: 100000.0

Max Scale: 0.0

Supports Advanced Queries: true

Supports Statistics: true

Has Labels: false

Can Modify Layer: true

Can Scale Symbols: false

Use Standardized Queries: true

Supports Datum Transformation: true

Extent:

XMin: -1.081229132191537E7
YMin: 3879394.0833129724
XMax: -1.0799975904616123E7
YMax: 3893963.0559360143
Spatial Reference: 102100  (3857)

Drawing Info:

Renderer:
Simple Renderer:
Symbol:
Style: esriSLSSolid
Color: [156, 160, 77, 255]
Width: 1
Label: N/A
Description: N/A
Transparency: 0
Labeling Info:

Feature Draw Order:

N/A

Advanced Query Capabilities:

Supports Statistics: true
Supports OrderBy: true
Supports Distinct: true
Supports Pagination: true
Supports Result Pagination Token: false
Supports TrueCurve: true
Supports Returning Query Extent: true
Supports Query With Distance: true
Supports Sql Expression: true
Supports Query With ResultType: true
Supports Returning Geometry Centroid: false
Supports Binning LOD: false
Supports Query With LOD Spatial Reference: false
Supports Percentile Statistics: true
Supports Having Clause: true
Supports Count Distinct: true
Supports Time Relation: true
Supports Sql Format: false
Supports Query Analytic: true
Supports Query With Cache Hint: false
Supports Query With Current User: true
Supports Query With Result Type: true

HasZ: false

HasM: false

Has Attachments: false

Has Last Edit Time: false

HTML Popup Type: esriServerHTMLPopupTypeAsHTMLText

Type ID Field: N/A

Fields:

• OBJECTID ( nullable: false, alias: OBJECTID, type: esriFieldTypeOID )
• Segment_ID ( nullable: true, alias: Segment_ID, type: esriFieldTypeInteger )
• SW_ID ( nullable: true, alias: SW_ID, type: esriFieldTypeInteger )
• SW_Type ( nullable: true, length: 255, alias: SW_Type, type: esriFieldTypeString )
• SW_Condition ( nullable: true, length: 255, alias: SW_Condition, type: esriFieldTypeString )
• SW_Material ( nullable: true, length: 255, alias: SW_Material, type: esriFieldTypeString )
• SW_Width ( nullable: true, length: 50, alias: SW_Width, type: esriFieldTypeString )
• SW_Location ( nullable: true, length: 50, alias: SW_Location, type: esriFieldTypeString )
• SW_Obstructions ( nullable: true, length: 255, alias: SW_Obstructions, type: esriFieldTypeString )
• SW_Shape_Length ( nullable: true, alias: SW_Shape_Length, type: esriFieldTypeDouble )
• SW_Start_X ( nullable: true, alias: SW_Start_X, type: esriFieldTypeDouble )
• SW_Start_Y ( nullable: true, alias: SW_Start_Y, type: esriFieldTypeDouble )
• SW_End_X ( nullable: true, alias: SW_End_X, type: esriFieldTypeDouble )
• SW_End_Y ( nullable: true, alias: SW_End_Y, type: esriFieldTypeDouble )
• SW_Comment ( nullable: true, length: 255, alias: SW_Comment, type: esriFieldTypeString )
• PvmtCARTE_ID ( nullable: true, length: 50, alias: pvmt CARTE_ID, type: esriFieldTypeString )
• Shape ( nullable: true, alias: Shape, type: esriFieldTypeGeometry )
• Shape.STLength() ( nullable: true, alias: Shape.STLength(), type: esriFieldTypeDouble )

Supported Operations:   Query   Query Attachments   Query Analytic   Generate Renderer   Return Updates
