Name: Street Striping Inventory

Display Field: SteetName

Type: Feature Layer

Geometry Type: esriGeometryPolyline

Description: This feature class contains line/polygon features representing street striping throughout the City of Grapevine.Data History & System Integration:Kimley-Horn Study (2021): The dataset was initially developed as part of a citywide engineering study conducted by Kimley-Horn beginning in 2021.OpenGOV Enterprise Asset Management System (Cartegraph) Integration: Active maintenance, work order tracking, and condition monitoring are maintained in the OpenGOV Enterprise Asset Management System (Cartegraph).*Consolidation Note: This dataset is designated to be merged with DBO.STREETS_Markings into a single unified pavement markings feature class.*

Service Item Id: 01688493526d4689bd555a10a36af2d7

Copyright Text: City of Grapevine Public Works Department — GIS Division & Streets Department Kimley-Horn and Associates, Inc.

Default Visibility: true

Max Result Window: N/A

Max Record Count: 2000

Standard Max Record Count No Geometry: 32000

Max Record Count Factor: 1

Standard MaxRecord Count: 8000

Tile Max Record Count: 4000

MaxSelectionCount: 2000

Supported Query Formats: JSON, geoJSON, PBF

Min Scale: 100000.0

Max Scale: 0.0

Supports Advanced Queries: true

Supports Statistics: true

Has Labels: false

Can Modify Layer: true

Can Scale Symbols: false

Use Standardized Queries: true

Supports Datum Transformation: true

Extent:

XMin: -1.0812100246133897E7
YMin: 3879407.2050765604
XMax: -1.0800330402238255E7
YMax: 3893395.3431071294
Spatial Reference: 102100  (3857)

Drawing Info:

Renderer:
Simple Renderer:
Symbol:
Style: esriSLSSolid
Color: [255, 215, 0, 255]
Width: 1
Label: N/A
Description: N/A
Transparency: 0
Labeling Info:

Feature Draw Order:

N/A

Advanced Query Capabilities:

Supports Statistics: true
Supports OrderBy: true
Supports Distinct: true
Supports Pagination: true
Supports Result Pagination Token: false
Supports TrueCurve: true
Supports Returning Query Extent: true
Supports Query With Distance: true
Supports Sql Expression: true
Supports Query With ResultType: true
Supports Returning Geometry Centroid: false
Supports Binning LOD: false
Supports Query With LOD Spatial Reference: false
Supports Percentile Statistics: true
Supports Having Clause: true
Supports Count Distinct: true
Supports Time Relation: true
Supports Sql Format: false
Supports Query Analytic: true
Supports Query With Cache Hint: false
Supports Query With Current User: true
Supports Query With Result Type: true

HasZ: false

HasM: false

Time Info:

Start Time Field: N/A
End Time Field: N/A
Track ID Field: N/A
Time Extent: N/A
Time Reference:
Time Zone: Central Standard Time
Respects Daylight Saving: true

Time Interval: N/A
Time Interval Units: N/A
Has Live Data: false

Has Attachments: false

Has Last Edit Time: false

HTML Popup Type: esriServerHTMLPopupTypeAsHTMLText

Type ID Field: N/A

Fields:

• OBJECTID ( nullable: false, alias: OBJECTID, type: esriFieldTypeOID )
• CarteID ( nullable: true, length: 20, alias: Cartegraph ID, type: esriFieldTypeString )
• PavementCartID ( nullable: true, length: 255, alias: Pavement Cartegraph ID, type: esriFieldTypeString )
• SteetName ( nullable: true, length: 100, alias: Steet Name, type: esriFieldTypeString )
• BeginStreet ( nullable: true, length: 100, alias: Begin Street, type: esriFieldTypeString )
• EndSt ( nullable: true, length: 100, alias: End St, type: esriFieldTypeString )
• EstimatedOCI ( nullable: true, alias: Estimated OCI, type: esriFieldTypeDouble )
• SpeedLimit ( nullable: true, alias: Speed Limit (mph), type: esriFieldTypeSmallInteger )
• StreetMaterial ( nullable: true, length: 50, alias: Street Material, type: esriFieldTypeString , Coded Values: [C: Concrete] , [A: Asphalt] , [C & A: Concrete & Asphalt] )
• MarkingType1 ( nullable: true, length: 40, alias: Marking Type (1), type: esriFieldTypeString , Coded Values: [Crosswalk: Crosswalk] , [School Crosswalk: School Crosswalk] , [Turn Lane: Turn Lane] , ...25 more... )
• MarkingLength1 ( nullable: true, alias: Length of Marking Type (1), type: esriFieldTypeSmallInteger )
• MarkingType2 ( nullable: true, length: 40, alias: Marking Type (2), type: esriFieldTypeString , Coded Values: [Crosswalk: Crosswalk] , [School Crosswalk: School Crosswalk] , [Turn Lane: Turn Lane] , ...25 more... )
• MarkingLength2 ( nullable: true, alias: Length of Marking Type (2), type: esriFieldTypeSmallInteger )
• MarkingType3 ( nullable: true, length: 40, alias: Marking Type (3), type: esriFieldTypeString , Coded Values: [Crosswalk: Crosswalk] , [School Crosswalk: School Crosswalk] , [Turn Lane: Turn Lane] , ...25 more... )
• MarkingLength3 ( nullable: true, alias: Length of Marking Type (3), type: esriFieldTypeSmallInteger )
• MarkingType4 ( nullable: true, length: 40, alias: Marking Type (4), type: esriFieldTypeString , Coded Values: [Crosswalk: Crosswalk] , [School Crosswalk: School Crosswalk] , [Turn Lane: Turn Lane] , ...25 more... )
• MarkingLength4 ( nullable: true, alias: Length of Marking Type (4), type: esriFieldTypeSmallInteger )
• MarkingType5 ( nullable: true, length: 40, alias: Marking Type (5), type: esriFieldTypeString , Coded Values: [Crosswalk: Crosswalk] , [School Crosswalk: School Crosswalk] , [Turn Lane: Turn Lane] , ...25 more... )
• MarkingLength5 ( nullable: true, alias: Length of Marking Type (5), type: esriFieldTypeSmallInteger )
• MarkingFinal ( nullable: true, length: 255, alias: Final Marking Combined, type: esriFieldTypeString )
• Thermo ( nullable: true, length: 3, alias: Thermo, type: esriFieldTypeString , Coded Values: [1: Yes] , [2: No] )
• Year ( nullable: true, length: 8, alias: Year, type: esriFieldTypeDate )
• GlobalID ( nullable: false, length: 38, alias: GlobalID, type: esriFieldTypeGlobalID )
• CreatedUser ( nullable: true, length: 255, alias: created_user, type: esriFieldTypeString )
• CreatedDate ( nullable: true, length: 8, alias: Created Date, type: esriFieldTypeDate )
• LastEditor ( nullable: true, length: 255, alias: Last Editor, type: esriFieldTypeString )
• LastEditDate ( nullable: true, length: 8, alias: Last Edit Date, type: esriFieldTypeDate )
• Shape ( nullable: true, alias: Shape, type: esriFieldTypeGeometry )
• Shape.STLength() ( nullable: true, alias: Shape.STLength(), type: esriFieldTypeDouble )

Supported Operations:   Query   Query Attachments   Query Analytic   Generate Renderer   Return Updates
