Name: Public Works Grid

Display Field: PERIMETER

Type: Feature Layer

Geometry Type: esriGeometryPolygon

Description: This feature class defines the standard index tiles and page layout boundaries for the City of Grapevine's Public Works utility mapbooks.Mapbook Architecture & Cartographic Standards:Cartographic Scale & Page Format: Designed for 11x17 inch (Tabloid) atlas page layouts at an exact engineering scale of 1"=400' (1: 4,800), ensuring consistent spatial coverage and readable text/symbol display across adjacent sheets.Engineering Provenance: Originally modeled and configured by consulting engineering firm Freese & Nichols, Inc. during municipal master utility mapping and system atlas updates.Operational Utility: Serves as the primary indexing layer for ArcGIS Map Series (formerly Data Driven Pages) to automate page generation for water distribution, wastewater collection, and stormwater infrastructure mapbooks used by field crews, inspectors, and engineering technicians.

Service Item Id: 5b5e0733b19f4797aae96d1303ae60e4

Copyright Text: Engineering design and grid development by Freese & Nichols, Inc. Curated and maintained by City of Grapevine Public Works GIS.

Default Visibility: true

Max Result Window: N/A

Max Record Count: 2000

Standard Max Record Count No Geometry: 32000

Max Record Count Factor: 1

Standard MaxRecord Count: 4000

Tile Max Record Count: 4000

MaxSelectionCount: 2000

Supported Query Formats: JSON, geoJSON, PBF

Min Scale: 125000.0

Max Scale: 0.0

Supports Advanced Queries: true

Supports Statistics: true

Has Labels: true

Can Modify Layer: true

Can Scale Symbols: false

Use Standardized Queries: true

Supports Datum Transformation: true

Extent:

XMin: -1.0813211001099342E7
YMin: 3878885.4695790526
XMax: -1.0797754484988673E7
YMax: 3895134.5074198605
Spatial Reference: 102100  (3857)

Drawing Info:

Renderer:
Simple Renderer:
Symbol:
Style: esriSFSSolid
Color: [130, 130, 130, 0]
Outline:
Style: esriSLSDash
Color: [0, 0, 0, 255]
Width: 1
Label: N/A
Description: N/A
Transparency: 0
Labeling Info:
Label Placement: esriServerPolygonPlacementAlwaysHorizontal
Label Expression: N/A
Use Coded Values: true
Symbol:
Color: [0, 0, 0, 255]
Background Color: N/A
Outline Color: N/A
Vertical Alignment: bottom
Horizontal Alignment: left
Right to Left: false
Angle: 0
XOffset: 0
YOffset: 0
Size: 10
Font Family: Times New Roman
Font Style: normal
Font Weight: normal
Font Decoration: none

Min. Scale: 0.0
Max. Scale: 0.0

Feature Draw Order:

N/A

Advanced Query Capabilities:

Supports Statistics: true
Supports OrderBy: true
Supports Distinct: true
Supports Pagination: true
Supports Result Pagination Token: false
Supports TrueCurve: true
Supports Returning Query Extent: true
Supports Query With Distance: true
Supports Sql Expression: true
Supports Query With ResultType: true
Supports Returning Geometry Centroid: false
Supports Binning LOD: false
Supports Query With LOD Spatial Reference: false
Supports Percentile Statistics: true
Supports Having Clause: true
Supports Count Distinct: true
Supports Time Relation: true
Supports Sql Format: false
Supports Query Analytic: true
Supports Query With Cache Hint: false
Supports Query With Current User: true
Supports Query With Result Type: true

HasZ: false

HasM: false

Has Attachments: false

Has Last Edit Time: false

HTML Popup Type: esriServerHTMLPopupTypeAsHTMLText

Type ID Field: N/A

Fields:

• OBJECTID ( nullable: false, alias: OBJECTID, type: esriFieldTypeOID )
• Perimeter ( nullable: true, alias: Perimeter, type: esriFieldTypeDouble )
• GridID ( nullable: true, length: 50, alias: Grid ID, type: esriFieldTypeString )
• GridNumber ( nullable: true, alias: Grid Number, type: esriFieldTypeInteger )
• GridID_N ( nullable: true, length: 254, alias: Grid ID North, type: esriFieldTypeString )
• GridID_NE ( nullable: true, length: 254, alias: Grid ID North East, type: esriFieldTypeString )
• GridID_E ( nullable: true, length: 254, alias: Grid ID E, type: esriFieldTypeString )
• GridID_SE ( nullable: true, length: 254, alias: Grid ID South East, type: esriFieldTypeString )
• GridID_S ( nullable: true, length: 254, alias: Grid ID S, type: esriFieldTypeString )
• GridID_SW ( nullable: true, length: 254, alias: Grid ID South West, type: esriFieldTypeString )
• GridID_W ( nullable: true, length: 254, alias: Grid ID West, type: esriFieldTypeString )
• GridID_NW ( nullable: true, length: 254, alias: Grid ID North West, type: esriFieldTypeString )
• Shape ( nullable: true, alias: Shape, type: esriFieldTypeGeometry )
• Shape.STArea() ( nullable: true, alias: Shape.STArea(), type: esriFieldTypeDouble )
• Shape.STLength() ( nullable: true, alias: Shape.STLength(), type: esriFieldTypeDouble )

Supported Operations:   Query   Query Attachments   Query Analytic   Generate Renderer   Return Updates

  Iteminfo   Thumbnail   Metadata
