Name: Plats Master

Display Field: PlatName

Type: Feature Layer

Geometry Type: esriGeometryPoint

Description: This enterprise geodatabase feature class serves as the authoritative administrative intake layer and master spatial index for all plats submitted to, reviewed by, and accepted by the City of Grapevine.Administrative Workflow & System Maintenance:Data Maintenance & Ingestion: Locations and non-spatial project metadata are updated and maintained directly by City of Grapevine Public Works administrative staff utilizing a specialized online management platform.Operational Role: Captures incoming submittals, active plat processing status, and administrative record-keeping for new subdivisions and re-plats prior to, or in coordination with, official county recording and long-term GIS indexing.

Service Item Id: 83071790af8741cf96350298b774164b

Copyright Text: City of Grapevine Public Works Department — Administrative, GIS & Engineering Divisions

Default Visibility: true

Max Result Window: N/A

Max Record Count: 2000

Standard Max Record Count No Geometry: 32000

Max Record Count Factor: 1

Standard MaxRecord Count: 32000

Tile Max Record Count: 8000

MaxSelectionCount: 2000

Supported Query Formats: JSON, geoJSON, PBF

Min Scale: 0.0

Max Scale: 0.0

Supports Advanced Queries: true

Supports Statistics: true

Has Labels: false

Can Modify Layer: true

Can Scale Symbols: false

Use Standardized Queries: true

Supports Datum Transformation: true

Extent:

XMin: -1.0812277166008096E7
YMin: 3879471.1839103797
XMax: -1.0799990191534314E7
YMax: 3894280.3748699175
Spatial Reference: 102100  (3857)

Drawing Info:

Renderer:
Simple Renderer:
Symbol:
Style: esriSMSCircle
Color: [142, 55, 45, 255]
Size: 4.0
Angle: 0.0
XOffset: 0
YOffset: 0
Outline:
[0, 0, 0, 255] Width: 0
Label: N/A
Description: N/A
Transparency: 0
Labeling Info:

Feature Draw Order:

N/A

Advanced Query Capabilities:

Supports Statistics: true
Supports OrderBy: true
Supports Distinct: true
Supports Pagination: true
Supports Result Pagination Token: false
Supports TrueCurve: true
Supports Returning Query Extent: true
Supports Query With Distance: true
Supports Sql Expression: true
Supports Query With ResultType: true
Supports Returning Geometry Centroid: false
Supports Binning LOD: false
Supports Query With LOD Spatial Reference: false
Supports Percentile Statistics: true
Supports Having Clause: true
Supports Count Distinct: true
Supports Time Relation: true
Supports Sql Format: false
Supports Query Analytic: true
Supports Query With Cache Hint: false
Supports Query With Current User: true
Supports Query With Result Type: true

HasZ: false

HasM: false

Time Info:

Start Time Field: N/A
End Time Field: N/A
Track ID Field: N/A
Time Extent: N/A
Time Reference:
Time Zone: Central Standard Time
Respects Daylight Saving: true

Time Interval: N/A
Time Interval Units: N/A
Has Live Data: false

Has Attachments: true

Has Last Edit Time: false

HTML Popup Type: esriServerHTMLPopupTypeAsHTMLText

Type ID Field: N/A

Fields:

• OBJECTID ( nullable: false, alias: OBJECTID, type: esriFieldTypeOID )
• PlatID ( nullable: true, alias: Plat ID, type: esriFieldTypeDouble )
• PlatName ( nullable: true, length: 255, alias: Plat Name, type: esriFieldTypeString )
• PlatType ( nullable: true, length: 25, alias: Plat Type, type: esriFieldTypeString , Coded Values: [Amended: Amended] , [Final: Final] , [Preliminary: Preliminary] , ...3 more... )
• Status ( nullable: true, length: 25, alias: Status, type: esriFieldTypeString , Coded Values: [Active: Active] , [Filed: Filed] , [Pending Approval: Pending Approval] , ...4 more... )
• CouncilDate ( nullable: true, length: 8, alias: Council Date, type: esriFieldTypeDate )
• DateApproved ( nullable: true, length: 8, alias: Date Approved, type: esriFieldTypeDate )
• FilingDate ( nullable: true, length: 8, alias: Filing Date, type: esriFieldTypeDate )
• Acreage ( nullable: true, alias: Acreage, type: esriFieldTypeDouble )
• Applicant ( nullable: true, length: 50, alias: Applicant, type: esriFieldTypeString )
• Comments ( nullable: true, length: 255, alias: Comments, type: esriFieldTypeString )
• DevelopmentType ( nullable: true, length: 50, alias: Development Type, type: esriFieldTypeString , Coded Values: [Single Family/Residential: Single Family/Residential] , [Multifamily: Multifamily] , [Mixed Use – Residential: Mixed Use – Residential] , ...7 more... )
• DrawerNumber ( nullable: true, alias: Drawer Number, type: esriFieldTypeDouble )
• InstrumentNumber ( nullable: true, length: 50, alias: Instrument Number, type: esriFieldTypeString )
• NumberOfPages ( nullable: true, alias: Number of Pages, type: esriFieldTypeDouble )
• NumberOfLots ( nullable: true, length: 255, alias: Number of Lots, type: esriFieldTypeString )
• Page ( nullable: true, length: 255, alias: Page, type: esriFieldTypeString )
• PublicHearingRequired ( nullable: true, length: 5, alias: Public Hearing Required?, type: esriFieldTypeString , Coded Values: [1: Yes] , [2: No] )
• SubdivisionCode ( nullable: true, length: 50, alias: Subdivision Code, type: esriFieldTypeString )
• Surveyor ( nullable: true, length: 255, alias: Surveyor, type: esriFieldTypeString )
• TADMap ( nullable: true, length: 10, alias: TAD Map, type: esriFieldTypeString )
• UtilityPlansIncluded ( nullable: true, length: 5, alias: Utility Plans Included?, type: esriFieldTypeString , Coded Values: [1: Yes] , [2: No] )
• Zoning ( nullable: true, length: 55, alias: Zoning, type: esriFieldTypeString )
• GISStatus ( nullable: true, length: 25, alias: GIS Status, type: esriFieldTypeString )
• ProjectManager ( nullable: true, length: 55, alias: Project Manager, type: esriFieldTypeString )
• last_edited_user ( nullable: true, length: 255, alias: last_edited_user, type: esriFieldTypeString )
• last_edited_date ( nullable: true, length: 8, alias: last_edited_date, type: esriFieldTypeDate )
• Shape ( nullable: true, alias: Shape, type: esriFieldTypeGeometry )
• CountyURL ( nullable: true, length: 500, alias: County URL, type: esriFieldTypeString )
• GlobalID ( nullable: false, length: 38, alias: GlobalID, type: esriFieldTypeGlobalID )
• SubmittalDate ( nullable: true, length: 8, alias: SubmittalDate, type: esriFieldTypeDate )

Supported Operations:   Query   Query Attachments   Query Analytic   Generate Renderer   Return Updates

  Iteminfo   Thumbnail   Metadata
