Name: Subdivisions

Display Field: SubName

Type: Feature Layer

Geometry Type: esriGeometryPolygon

Description: This enterprise SDE feature class serves as the master spatial boundary layer for all platted subdivisions and additions within the City of Grapevine's corporate limits and Extra-Territorial Jurisdiction (ETJ).Geodatabase Lineage & Operational Context:Plat Integration: Polygon geometries and subdivision names are generated directly from official Public Works recorded plat filings, establishing spatial continuity between real property land development and municipal GIS layers.Departmental Use: Serves as a primary cadastral index layer for Public Works, Planning & Development Services, Emergency Services (911), and Utility Billing for indexing development projects, address verification, and neighborhood-level reporting.

Service Item Id: 83071790af8741cf96350298b774164b

Copyright Text: City of Grapevine Public Works Department — GIS & Engineering Divisions City of Grapevine Planning & Development Services

Default Visibility: false

Max Result Window: N/A

Max Record Count: 2000

Standard Max Record Count No Geometry: 32000

Max Record Count Factor: 1

Standard MaxRecord Count: 4000

Tile Max Record Count: 4000

MaxSelectionCount: 2000

Supported Query Formats: JSON, geoJSON, PBF

Min Scale: 0.0

Max Scale: 0.0

Supports Advanced Queries: true

Supports Statistics: true

Has Labels: false

Can Modify Layer: true

Can Scale Symbols: false

Use Standardized Queries: true

Supports Datum Transformation: true

Extent:

XMin: -1.08124778894034E7
YMin: 3879421.5664310292
XMax: -1.0799771030324534E7
YMax: 3894942.586035058
Spatial Reference: 102100  (3857)

Drawing Info:

Renderer:
Simple Renderer:
Symbol:
Style: esriSFSSolid
Color: [185, 179, 252, 255]
Outline:
Style: esriSLSSolid
Color: [169, 0, 230, 255]
Width: 1
Label: N/A
Description: N/A
Transparency: 0
Labeling Info:

Feature Draw Order:

N/A

Advanced Query Capabilities:

Supports Statistics: true
Supports OrderBy: true
Supports Distinct: true
Supports Pagination: true
Supports Result Pagination Token: false
Supports TrueCurve: true
Supports Returning Query Extent: true
Supports Query With Distance: true
Supports Sql Expression: true
Supports Query With ResultType: true
Supports Returning Geometry Centroid: false
Supports Binning LOD: false
Supports Query With LOD Spatial Reference: false
Supports Percentile Statistics: true
Supports Having Clause: true
Supports Count Distinct: true
Supports Time Relation: true
Supports Sql Format: false
Supports Query Analytic: true
Supports Query With Cache Hint: false
Supports Query With Current User: true
Supports Query With Result Type: true

HasZ: false

HasM: false

Has Attachments: false

Has Last Edit Time: false

HTML Popup Type: esriServerHTMLPopupTypeAsHTMLText

Type ID Field: N/A

Fields:

• OBJECTID ( nullable: false, alias: OBJECTID, type: esriFieldTypeOID )
• SubName ( nullable: true, length: 75, alias: Subdivision Name, type: esriFieldTypeString )
• Shape ( nullable: true, alias: Shape, type: esriFieldTypeGeometry )
• LastUser ( nullable: true, length: 50, alias: Last User, type: esriFieldTypeString )
• LastEdit ( nullable: true, length: 8, alias: Last Edit Date, type: esriFieldTypeDate )
• GlobalID ( nullable: false, length: 38, alias: GlobalID, type: esriFieldTypeGlobalID )
• Shape.STArea() ( nullable: true, alias: Shape.STArea(), type: esriFieldTypeDouble )
• Shape.STLength() ( nullable: true, alias: Shape.STLength(), type: esriFieldTypeDouble )

Supported Operations:   Query   Query Attachments   Query Analytic   Generate Renderer   Return Updates

  Iteminfo   Thumbnail   Metadata
