Name: Stream Monitoring

Display Field: SiteID

Type: Feature Layer

Geometry Type: esriGeometryPoint

Description: This point feature class represents fixed sampling locations along creeks, tributaries, and drainage channels where the Environmental Services Department regularly collects water samples and performs environmental testing.Environmental Monitoring & Compliance Workflow:Program Purpose: Tracks long-term surface water quality trends, identifies illicit discharge impacts, and monitors ecological health across local watersheds (e.g., Big Bear Creek, Denton Creek tributaries).Testing Parameters: Used to record field measurements and laboratory analytical data including pH, dissolved oxygen, turbidity, conductivity, temperature, bacterial indicators, and pollutant concentrations.Maintenance & Update Frequency: Periodic / As Needed (Updated when new monitoring stations are established or sampling access locations change)Process Step (Lineage Description):Station Establishment: Sampling sites selected by Environmental Services staff based on watershed coverage, access considerations, and stormwater program requirements.Attribute Integration: Station IDs, stream names, watersheds, and monitoring program protocols populated and maintained within the enterprise geodatabase.

Service Item Id: cfba511bdbea48c2adcd76eff1340ded

Copyright Text: City of Grapevine Public Works Department - Environmental Services Division, PW GIS Division

Default Visibility: true

Max Result Window: N/A

Max Record Count: 2000

Standard Max Record Count No Geometry: 32000

Max Record Count Factor: 1

Standard MaxRecord Count: 32000

Tile Max Record Count: 8000

MaxSelectionCount: 2000

Supported Query Formats: JSON, geoJSON, PBF

Min Scale: 100000.0

Max Scale: 0.0

Supports Advanced Queries: true

Supports Statistics: true

Has Labels: false

Can Modify Layer: true

Can Scale Symbols: false

Use Standardized Queries: true

Supports Datum Transformation: true

Extent:

XMin: -1.0812413129533106E7
YMin: 3879377.147683665
XMax: -1.079447538728826E7
YMax: 3894050.643895198
Spatial Reference: 102100  (3857)

Drawing Info:

Renderer:
Simple Renderer:
Symbol:
Label: N/A
Description: N/A
Transparency: 0
Labeling Info:

Feature Draw Order:

N/A

Advanced Query Capabilities:

Supports Statistics: true
Supports OrderBy: true
Supports Distinct: true
Supports Pagination: true
Supports Result Pagination Token: false
Supports TrueCurve: true
Supports Returning Query Extent: true
Supports Query With Distance: true
Supports Sql Expression: true
Supports Query With ResultType: true
Supports Returning Geometry Centroid: false
Supports Binning LOD: false
Supports Query With LOD Spatial Reference: false
Supports Percentile Statistics: true
Supports Having Clause: true
Supports Count Distinct: true
Supports Time Relation: true
Supports Sql Format: false
Supports Query Analytic: true
Supports Query With Cache Hint: false
Supports Query With Current User: true
Supports Query With Result Type: true

HasZ: false

HasM: false

Has Attachments: false

Has Last Edit Time: false

HTML Popup Type: esriServerHTMLPopupTypeAsHTMLText

Type ID Field: N/A

Fields:

• OBJECTID ( nullable: false, alias: OBJECTID, type: esriFieldTypeOID )
• SiteID ( nullable: true, length: 254, alias: Site Identifier, type: esriFieldTypeString )
• LocSubWtsd ( nullable: true, length: 75, alias: Local Sub-Watershed, type: esriFieldTypeString )
• Northing ( nullable: true, alias: Northing, type: esriFieldTypeDouble )
• Easting ( nullable: true, alias: Easting, type: esriFieldTypeDouble )
• LastUpdate ( nullable: true, length: 8, alias: Last Edit Date, type: esriFieldTypeDate )
• LastUser ( nullable: true, length: 50, alias: Last User, type: esriFieldTypeString )
• Shape ( nullable: true, alias: Shape, type: esriFieldTypeGeometry )
• GlobalID ( nullable: false, length: 38, alias: GlobalID, type: esriFieldTypeGlobalID )
• created_user ( nullable: true, length: 255, alias: created_user, type: esriFieldTypeString )
• created_date ( nullable: true, length: 8, alias: created_date, type: esriFieldTypeDate )

Relationships:

• DBO.ENVSAMPLING_StreamSamples (0) -- Related To: Stream Samples (7)

Supported Operations:   Query   Query Attachments   Query Analytic   Query Related Records   Generate Renderer   Return Updates
