View In:   ArcGIS Online Map Viewer

Name: Stream Monitoring

Display Field: SiteID

Type: Feature Layer

Geometry Type: esriGeometryPoint

Description: This point feature class represents fixed sampling locations along creeks, tributaries, and drainage channels where the Environmental Services Department regularly collects water samples and performs environmental testing.Environmental Monitoring & Compliance Workflow:Program Purpose: Tracks long-term surface water quality trends, identifies illicit discharge impacts, and monitors ecological health across local watersheds (e.g., Big Bear Creek, Denton Creek tributaries).Testing Parameters: Used to record field measurements and laboratory analytical data including pH, dissolved oxygen, turbidity, conductivity, temperature, bacterial indicators, and pollutant concentrations.Maintenance & Update Frequency: Periodic / As Needed (Updated when new monitoring stations are established or sampling access locations change)Process Step (Lineage Description):Station Establishment: Sampling sites selected by Environmental Services staff based on watershed coverage, access considerations, and stormwater program requirements.Attribute Integration: Station IDs, stream names, watersheds, and monitoring program protocols populated and maintained within the enterprise geodatabase.

Service Item Id: 64d6c86b88e44a03bcab62869ffd3f59

Copyright Text: City of Grapevine Public Works Department - Environmental Services Division, PW GIS Division

Default Visibility: true

Max Result Window: N/A

Max Record Count: 2000

Standard Max Record Count No Geometry: 32000

Max Record Count Factor: 1

Standard MaxRecord Count: 32000

Tile Max Record Count: 8000

MaxSelectionCount: 0

Supported Query Formats: JSON, geoJSON, PBF

Min Scale: 0.0

Max Scale: 0.0

Supports Advanced Queries: true

Supports Statistics: true

Can Scale Symbols: false

Use Standardized Queries: true

Supports ValidateSQL: true

Supports Calculate: true

Supports Datum Transformation: true

Extent:

XMin: 2389181.1839496344
YMin: 7006480.499837056
XMax: 2438074.543183714
YMax: 7046057.192337066
Spatial Reference: 102738  (2276)

Drawing Info:

Renderer:
Simple Renderer:
Symbol:
Label: N/A
Description: N/A
Transparency: 0
Labeling Info:

Feature Draw Order:

N/A

Advanced Query Capabilities:

Supports Statistics: true
Supports OrderBy: true
Supports Distinct: true
Supports Pagination: true
Supports Result Pagination Token: false
Supports TrueCurve: false
Supports Returning Query Extent: true
Supports Query With Distance: true
Supports Sql Expression: true
Supports Query With ResultType: true
Supports Returning Geometry Centroid: false
Supports Binning LOD: false
Supports Query With LOD Spatial Reference: false
Supports Percentile Statistics: true
Supports Having Clause: true
Supports Count Distinct: true
Supports Time Relation: false
Supports Sql Format: false
Supports Query Analytic: true
Supports Query With Cache Hint: false
Supports Query With Current User: true
Supports Query With Result Type: true

HasZ: false

HasM: false

Has Attachments: false

Has Last Edit Time: false

HTML Popup Type: esriServerHTMLPopupTypeAsHTMLText

Type ID Field:

Fields:

• OBJECTID ( modelName: OBJECTID, nullable: false, editable: false, defaultValue: N/A, alias: OBJECTID, type: esriFieldTypeOID )
• SiteID ( modelName: Site_ID, nullable: true, editable: true, defaultValue: N/A, length: 254, alias: Site Identifier, type: esriFieldTypeString )
• LocSubWtsd ( modelName: LocalSubWTSD, nullable: true, editable: true, defaultValue: N/A, length: 75, alias: Local Sub-Watershed, type: esriFieldTypeString )
• Northing ( modelName: Northing, nullable: true, editable: true, defaultValue: N/A, alias: Northing, type: esriFieldTypeDouble )
• Easting ( modelName: Easting, nullable: true, editable: true, defaultValue: N/A, alias: Easting, type: esriFieldTypeDouble )
• LastUpdate ( modelName: LastUpdate, nullable: true, editable: false, defaultValue: N/A, length: 8, alias: Last Edit Date, type: esriFieldTypeDate )
• LastUser ( modelName: LastUser, nullable: true, editable: false, defaultValue: N/A, length: 50, alias: Last User, type: esriFieldTypeString )
• GlobalID ( modelName: GlobalID, nullable: false, editable: false, defaultValue: N/A, length: 38, alias: GlobalID, type: esriFieldTypeGlobalID )
• created_user ( modelName: created_user, nullable: true, editable: false, defaultValue: N/A, length: 255, alias: created_user, type: esriFieldTypeString )
• created_date ( modelName: created_date, nullable: true, editable: false, defaultValue: N/A, length: 8, alias: created_date, type: esriFieldTypeDate )

Templates:

• Name: Stream Monitoring
  Description:
  Prototype:
  SiteID: null
  LocSubWtsd: null
  Northing: null
  Easting: null

  Drawing Tool: esriFeatureEditToolPoint

Relationships:

• DBO.ENVSAMPLING_StreamSamples (0) -- Related To: StreamSamples (7)

Capabilities: Query,Create,Update,Delete,Uploads,Editing

Sync Can Return Changes: false

Is Data Versioned: false

Supports Rollback On Failure: true

Supports ApplyEdits With Global Ids: true

Edit Fields Info:

• Creation Date Field: created_date
• Creator Field: created_user
• Edit Date Field: LastUpdate
• Editor Field: LastUser

Supports Query With Historic Moment: false

Supports Coordinates Quantization: true

Child Resources:

Supported Operations:   Query   Query Analytic   Query Related Records   Apply Edits   Add Features   Update Features   Delete Features   Calculate   Append   Validate SQL   Generate Renderer   Return Updates   Iteminfo   Thumbnail   Metadata
