Name: Municipal Setting Designation Sites

Display Field: ApplicantName

Type: Feature Layer

Geometry Type: esriGeometryPolygon

Description: This polygon feature class represents properties certified under Texas Commission on Environmental Quality (TCEQ) Municipal Setting Designation (MSD) provisions. An MSD certifies that groundwater beneath designated properties is contaminated above protective potable levels and prohibits its future use as drinking water.Source & Lineage:Data Source: TCEQ MSD Program - https://www.tceq.texas.gov/remediation/msd-certificateGeometry Creation: Digitized by City of Grapevine Public Works GIS from site boundaries and legal descriptions; attributes populated from state certification documents.Last Updated: August 2, 2023.Maintenance & Update Frequency: As Needed (Updated upon city adoption of new MSD ordinances or TCEQ certification issuances)Process Step (Lineage Description):Source Gathering: MSD site filings and certificates were downloaded from the TCEQ MSD program portal ([https://www.tceq.texas.gov/remediation/msd-certificate](https://www.tceq.texas.gov/remediation/msd-certificate)).Digitizing: Geometries were created by GIS staff using property boundaries and deed descriptions matching city-adopted MSD ordinances.Attribute Population: Certificate numbers, enactment dates, and site details were populated (Last updated August 2, 2023).

Service Item Id: d6300b0c4d494099a2b33d2d15c25778

Copyright Text: Texas Commission on Environmental Quality (TCEQ), PW GIS Division

Default Visibility: true

Max Result Window: N/A

Max Record Count: 2000

Standard Max Record Count No Geometry: 32000

Max Record Count Factor: 1

Standard MaxRecord Count: 4000

Tile Max Record Count: 4000

MaxSelectionCount: 2000

Supported Query Formats: JSON, geoJSON, PBF

Min Scale: 0.0

Max Scale: 0.0

Supports Advanced Queries: true

Supports Statistics: true

Has Labels: false

Can Modify Layer: true

Can Scale Symbols: false

Use Standardized Queries: true

Supports Datum Transformation: true

Extent:

XMin: -1.0809351253751034E7
YMin: 3885288.2604021463
XMax: -1.0805430008426813E7
YMax: 3887645.7622358943
Spatial Reference: 102100  (3857)

Drawing Info:

Renderer:
Simple Renderer:
Symbol:
Style: esriSFSSolid
Color: [185, 179, 252, 255]
Outline:
Style: esriSLSSolid
Color: [230, 0, 0, 255]
Width: 1
Label: N/A
Description: N/A
Transparency: 0
Labeling Info:

Feature Draw Order:

N/A

Advanced Query Capabilities:

Supports Statistics: true
Supports OrderBy: true
Supports Distinct: true
Supports Pagination: true
Supports Result Pagination Token: false
Supports TrueCurve: true
Supports Returning Query Extent: true
Supports Query With Distance: true
Supports Sql Expression: true
Supports Query With ResultType: true
Supports Returning Geometry Centroid: false
Supports Binning LOD: false
Supports Query With LOD Spatial Reference: false
Supports Percentile Statistics: true
Supports Having Clause: true
Supports Count Distinct: true
Supports Time Relation: true
Supports Sql Format: false
Supports Query Analytic: true
Supports Query With Cache Hint: false
Supports Query With Current User: true
Supports Query With Result Type: true

HasZ: false

HasM: false

Has Attachments: true

Has Last Edit Time: false

HTML Popup Type: esriServerHTMLPopupTypeAsHTMLText

Type ID Field: N/A

Fields:

• OBJECTID ( nullable: false, alias: OBJECTID, type: esriFieldTypeOID )
• MSDNumber ( nullable: true, alias: MSD Application Number, type: esriFieldTypeSmallInteger )
• ApplicantName ( nullable: true, length: 150, alias: Applicant Name, type: esriFieldTypeString )
• Location ( nullable: true, length: 255, alias: Location, type: esriFieldTypeString )
• Acres ( nullable: true, alias: Acres, type: esriFieldTypeDouble )
• Status ( nullable: true, length: 25, alias: Status, type: esriFieldTypeString )
• CertificationDate ( nullable: true, length: 8, alias: Certification Date, type: esriFieldTypeDate )
• Notes ( nullable: true, length: 500, alias: Notes, type: esriFieldTypeString )
• Shape ( nullable: true, alias: SHAPE, type: esriFieldTypeGeometry )

Supported Operations:   Query   Query Attachments   Query Analytic   Generate Renderer   Return Updates

  Iteminfo   Thumbnail   Metadata
