Name: Pavement

Display Field: StreetName

Type: Feature Layer

Geometry Type: esriGeometryPolyline

Description: This feature class represents street pavement segments throughout the City of Grapevine, broken down by pavement composition and physical extent to support municipal roadway maintenance and capital planning.System Integration & Inspection History:OpenGOV EAM (Cartegraph) Linkage: This dataset is directly integrated with the OpenGOV Enterprise Asset Management System (Cartegraph) for work orders, asset tracking, and condition monitoring.Field Measurements: Segment lengths and widths were field-measured and segmented based on material/pavement type.Pavement Condition Audits: Dedicated attribute fields record major citywide street condition inspections performed in **2018** and **2023**.Maintenance: Ongoing inspections, PCI (Pavement Condition Index) scores, and maintenance histories are actively managed within OpenGOV EAM (Cartegraph).

Service Item Id: 9ecee664edd648dbb8706e1333022bd5

Copyright Text: City of Grapevine Public Works Department — GIS Division & Streets Department

Default Visibility: true

Max Result Window: N/A

Max Record Count: 2000

Standard Max Record Count No Geometry: 32000

Max Record Count Factor: 1

Standard MaxRecord Count: 8000

Tile Max Record Count: 4000

MaxSelectionCount: 2000

Supported Query Formats: JSON, geoJSON, PBF

Min Scale: 0.0

Max Scale: 0.0

Supports Advanced Queries: true

Supports Statistics: true

Has Labels: false

Can Modify Layer: true

Can Scale Symbols: false

Use Standardized Queries: true

Supports Datum Transformation: true

Extent:

XMin: -1.0812294863367597E7
YMin: 3879415.05445537
XMax: -1.0799980017695641E7
YMax: 3893948.73356768
Spatial Reference: 102100  (3857)

Drawing Info:

Renderer:
Class Breaks Renderer:
Field: EstimatedOCI
Min. Value: 0.0
ClassBreakInfos:
• Class Maximum Value: 29.899999999999999
  Label: Poor < 30
  Description: N/A
  Symbol:
  Style: esriSLSSolid
  Color: [255, 0, 0, 255]
  Width: 1
• Class Maximum Value: 59.899999999999999
  Label: Fair 30 - 59
  Description: N/A
  Symbol:
  Style: esriSLSSolid
  Color: [255, 170, 0, 255]
  Width: 1
• Class Maximum Value: 79.989999999999995
  Label: Good 60 - 79
  Description: N/A
  Symbol:
  Style: esriSLSSolid
  Color: [0, 112, 255, 255]
  Width: 1
• Class Maximum Value: 100
  Label: Excellent > 80
  Description: N/A
  Symbol:
  Style: esriSLSSolid
  Color: [56, 168, 0, 255]
  Width: 1
Transparency: 0
Labeling Info:

Feature Draw Order:

N/A

Advanced Query Capabilities:

Supports Statistics: true
Supports OrderBy: true
Supports Distinct: true
Supports Pagination: true
Supports Result Pagination Token: false
Supports TrueCurve: true
Supports Returning Query Extent: true
Supports Query With Distance: true
Supports Sql Expression: true
Supports Query With ResultType: true
Supports Returning Geometry Centroid: false
Supports Binning LOD: false
Supports Query With LOD Spatial Reference: false
Supports Percentile Statistics: true
Supports Having Clause: true
Supports Count Distinct: true
Supports Time Relation: true
Supports Sql Format: false
Supports Query Analytic: true
Supports Query With Cache Hint: false
Supports Query With Current User: true
Supports Query With Result Type: true

HasZ: false

HasM: false

Time Info:

Start Time Field: N/A
End Time Field: N/A
Track ID Field: N/A
Time Extent: N/A
Time Reference:
Time Zone: Central Standard Time
Respects Daylight Saving: true

Time Interval: N/A
Time Interval Units: N/A
Has Live Data: false

Has Attachments: false

Has Last Edit Time: false

HTML Popup Type: esriServerHTMLPopupTypeAsHTMLText

Type ID Field: N/A

Fields:

• OBJECTID ( nullable: false, alias: OBJECTID, type: esriFieldTypeOID )
• CarteID ( nullable: true, length: 50, alias: Cartegraph ID, type: esriFieldTypeString )
• EstimatedOCI ( nullable: true, alias: Estimated OCI, type: esriFieldTypeDouble )
• EstimatedOCR ( nullable: true, length: 255, alias: Estimated OCR, type: esriFieldTypeString )
• PCIScore2018 ( nullable: true, alias: PCI Score 2018, type: esriFieldTypeSmallInteger )
• PCIScore2023 ( nullable: true, alias: PCI Score 2023, type: esriFieldTypeSmallInteger )
• FullRoadName ( nullable: true, length: 60, alias: Full Road Name, type: esriFieldTypeString )
• Aliases ( nullable: true, length: 45, alias: Aliases, type: esriFieldTypeString )
• RoadType ( nullable: true, length: 25, alias: Road Type, type: esriFieldTypeString )
• Culdesac ( nullable: true, length: 10, alias: Culdesac?, type: esriFieldTypeString )
• NumberOfLanes ( nullable: true, alias: Number of Lanes, type: esriFieldTypeSmallInteger )
• LaneMiles ( nullable: true, alias: Lane Miles, type: esriFieldTypeDouble )
• AssessmentGroup ( nullable: true, length: 255, alias: Assessment Group, type: esriFieldTypeString )
• FunctionalClassification ( nullable: true, length: 50, alias: Functional Classification, type: esriFieldTypeString )
• PavementClassification ( nullable: true, length: 50, alias: Pavement Classification, type: esriFieldTypeString )
• Custodian ( nullable: true, length: 50, alias: Custodian, type: esriFieldTypeString )
• Subdivison ( nullable: true, length: 100, alias: Subdivison, type: esriFieldTypeString )
• InstalledDate ( nullable: true, length: 8, alias: Installed Date, type: esriFieldTypeDate )
• Width ( nullable: true, alias: Width (ft), type: esriFieldTypeDouble )
• MeasuredLength ( nullable: true, alias: Measured Length (ft), type: esriFieldTypeDouble )
• Shape ( nullable: true, alias: Shape, type: esriFieldTypeGeometry )
• Shape.STLength() ( nullable: true, alias: Shape.STLength(), type: esriFieldTypeDouble )
• DBO.STREETS_Pavement.Area ( nullable: true, alias: DBO.STREETS_Pavement.Area, type: esriFieldTypeDouble )
• PCIChange ( nullable: true, alias: PCIChange, type: esriFieldTypeDouble )
• PCITrend ( nullable: true, length: 255, alias: PCITrend, type: esriFieldTypeString )
• PavemenetLength ( nullable: true, alias: PavemenetLength, type: esriFieldTypeDouble )
